Omron Q2A Series Technical Manual

11.19 Defaults by Drive Model and Duty Rating ND/HD
492 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
Parameter Unit
Drive Model
4075 4089 4103 4140
C6-01 ND/HD Duty Selection -
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
E2-11 Motor Rated Power (kW)
(E4-11 M2 Rated Power (kW))
kW 30 37 37 45 45 55 55 75
C6-02 Carrier Frequency Selection - 1 7 1 7 1 7 1 7
E2-01 Mot Rated Current (FLA)
(E4-01 M2 Rated Current (FLA))
A 52.3 65.6 65.6 79.7 79.7 95 95 130
E2-02 Mot Rated Slip
(E4-02 M2 Rated Slip)
Hz 1.8 1.33 1.33 1.6 1.6 1.46 1.46 1.39
E2-03 Mot No-Load Current
(E4-03 M2 No-Load Current)
A 10.9 19.1 19.1 22 22 24 24 36
E2-05 Motor L-L Resistance
(E4-05 M2 L-L Resistance)
Ω 0.269 0.155 0.155 0.122 0.122 0.088 0.088 0.092
E2-06 Motor Leak Inductance
(E4-06 M2 Leak Inductance)
% 20.7 18.8 18.8 19.9 19.9 20 20 20
E2-10 Motor Iron Loss
(E4-10 M2 Iron Loss)
W 750 925 925 1125 1125 1260 1260 1600
E5-01 PM Mot Code Selection - 1242 1242 1243 1243 1244 1244 1245 1245
L2-02 RideThrough Time@Power Loss s 2 2 2 2 2 2 2 2
L2-03 Min Baseblck Time s 1.1 1.1 1.1 1.2 1.2 1.2 1.2 1.3
L2-04 Powloss Ramp Time@recovery s 0.6 0.6 0.6 0.6 0.6 1 1 1
L2-05 UV Detection Lvl (Uv1) - 380 380 380 380 380 380 380 380
L3-24 Acc@Rated Torque s 0.323 0.32 0.32 0.387 0.387 0.317 0.317 0.533
L8-02 Overheat Alm Level °C 120 120 115 115 126 131 120 120
L8-09 Ground Fault Selection - 1 1 1 1 1 1 1 1
L8-38 Carrier Reduction Mode - 2 2 2 2 2 2 2 2
n1-01 HuntPrev Selection - 2 2 2 2 2 2 2 2
n1-03 HuntPrev Time Constant ms 10 10 10 10 10 10 30 30
n1-16 HuntPrev HiFc Gain - 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
n5-02 Mot Inertia Acceleration Time s 0.323 0.32 0.32 0.387 0.387 0.317 0.317 0.533
n8-11 Observ.Calc Gain2 - 50.0 50.0 50.0 50.0 50.0 50.0 50.0 50.0
Parameter Unit
Drive Model
4168 4208 4250 4296
C6-01 ND/HD Duty Selection -
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
E2-11 Motor Rated Power (kW)
(E4-11 M2 Rated Power (kW))
kW 75 90 90 110 110 132 132 160
b3-04 SpSrch V/F Gain % 60 60 60 60 60 60 60 60
b3-06 Speed Curr Lev1 for Estimation - 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7
b3-08 Speed ACR PGain for Estimation - 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8
b3-26 Dir. Determ. Level - 1000 1000 1000 1000 1000 1000 1000 1000
b8-03 eSave Filter Time s 2.00 2.00 2.00 2.00 2.00 2.00 2.00 2.00
b8-04 eSave Coef. Value - 46.2 38.91 38.91 36.23 36.23 32.79 32.79 30.13
C5-17 Motor Inertia
(C5-37 M2 Inertia)
kgm
2
0.90 1.10 1.10 1.90 1.90 2.10 2.10 3.30
C6-02 Carrier Frequency Selection - 1 7 1 7 1 7 1 7
E2-01 Mot Rated Current (FLA)
(E4-01 M2 Rated Current (FLA))
A 130 156 156 190 190 223 223 270
