Omron Q2A Series Technical Manual

Parameter List
11
11.19 Defaults by Drive Model and Duty Rating ND/HD
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 493
Parameter Unit
Drive Model
4168 4208 4250 4296
C6-01 ND/HD Duty Selection -
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
E2-11 Motor Rated Power (kW)
(E4-11 M2 Rated Power (kW))
kW 75 90 90 110 110 132 132 160
E2-02 Mot Rated Slip
(E4-02 M2 Rated Slip)
Hz 1.39 1.4 1.4 1.4 1.4 1.38 1.38 1.35
E2-03 Mot No-Load Current
(E4-03 M2 No-Load Current)
A 36 40 40 49 49 58 58 70
E2-05 Motor L-L Resistance
(E4-05 M2 L-L Resistance)
Ω 0.092 0.056 0.056 0.046 0.046 0.035 0.035 0.029
E2-06 Motor Leak Inductance
(E4-06 M2 Leak Inductance)
% 20 20 20 20 20 20 20 20
E2-10 Motor Iron Loss
(E4-10 M2 Iron Loss)
W 1600 1760 1760 2150 2150 2350 2350 2850
E5-01 PM Mot Code Selection - 1246 1246 1247 1247 1248 1248 1249 1249
L2-02 RideThrough Time@Power Loss s 2 2 2 2 2 2 2 2
L2-03 Min Baseblck Time s 1.3 1.5 1.5 1.7 1.7 1.7 1.7 1.8
L2-04 Powloss Ramp Time@recovery s 1 1 1 1 1 1 1 1
L2-05 UV Detection Lvl (Uv1) - 380 380 380 380 380 380 380 380
L3-24 Acc@Rated Torque s 0.533 0.592 0.592 0.646 0.646 0.673 0.673 0.777
L8-02 Overheat Alm Level °C 110 110 105 105 120 120 120 120
L8-09 Ground Fault Selection - 1 1 1 1 1 1 1 1
L8-38 Carrier Reduction Mode - 2 2 2 2 2 2 2 2
n1-01 HuntPrev Selection - 2 2 2 2 2 2 2 2
n1-03 HuntPrev Time Constant ms 30 30 30 30 30 30 30 30
n1-16 HuntPrev HiFc Gain - 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
n5-02 Mot Inertia Acceleration Time s 0.533 0.592 0.592 0.646 0.646 0.673 0.673 0.777
n8-11 Observ.Calc Gain2 - 50.0 50.0 50.0 50.0 50.0 50.0 50.0 50.0
Parameter Unit
Drive Model
4371 4389 4453 4568
C6-01 ND/HD Duty Selection -
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
E2-11 Motor Rated Power (kW)
(E4-11 M2 Rated Power (kW))
kW 160 200 200 220 220 250 250 315
b3-04 SpSrch V/F Gain % 60 60 60 60 60 60 60 60
b3-06 Speed Curr Lev1 for Estimation - 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7
b3-08 Speed ACR PGain for Estimation - 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8
b3-26 Dir. Determ. Level - 1000 1000 1000 1000 1000 1000 1000 1000
b8-03 eSave Filter Time s 2.00 2.00 2.00 2.00 2.00 2.00 2.00 2.00
b8-04 eSave Coef. Value - 30.13 30.57 30.57 27.13 27.13 21.76 21.76 21.76
C5-17 Motor Inertia
(C5-37 M2 Inertia)
kgm
2
3.30 3.60 3.60 4.10 4.10 6.50 6.50 11.00
C6-02 Carrier Frequency Selection - 1 7 1 7 1 7 1 7
E2-01 Mot Rated Current (FLA)
(E4-01 M2 Rated Current (FLA))
A 270 310 310 370 370 500 500 500
E2-02 Mot Rated Slip
(E4-02 M2 Rated Slip)
Hz 1.35 1.3 1.3 1.3 1.3 1.25 1.25 1.25
E2-03 Mot No-Load Current
(E4-03 M2 No-Load Current)
A 70 81 81 96 96 130 130 130
