Omron Q2A Series Technical Manual

Parameter List
11
11.20 Parameters Changed by PM Motor Code Selection
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 497
Parameter Unit Motor Code (setting value of E5-01)
E5-24 PM BackEMF L-L Vrms
(mV/rpm)
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-09 Min Output Frequency Hz 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4
C5-17 Motor Inertia kgm
2
0.046 0.055 0.064 0.116 0.140 0.259 0.31 0.42
L3-24 Acc@Rated Torque
*1
s 0.102 0.101 0.098 0.130 0.127 0.193 0.191 0.187
n5-02 Mot Inertia Acceleration
Time
s 0.102 0.101 0.098 0.130 0.127 0.193 0.191 0.187
n8-49 Heavy Load Id Current % -15.5 -17.9 -15.1 -16.8 -14.1 -8.8 -9.6 -10.3
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
Table 11.6 SSR1 Series Motor Code Setting for Specification of 400 V at 1750 min
-1
(r/min)
Parameter Unit Motor Code (setting value of E5-01)
E5-01 PM Mot Code Selection - 1247 1248 1249 124A
Voltage Class V 400 400 400 400
Capacity kW 90 110 132 160
Motor Rotation Speed min
-1
1750 1750 1750 1750
E5-02 PM Mot Rated Power (kW) kW 90.00 110.00 132.00 160.00
E5-03 PM Mot Rated Current (FLA) A 160.4 183.3 222.9 267.7
E5-04 PM Mot Pole Count - 6 6 6 6
E5-05 PM Mot Resistance (Ohms/Phase) Ω 0.019 0.017 0.012 0.008
E5-06 PM d-Axis Inductance (mH/Phase) mH 1.54 1.44 1.21 0.97
E5-07 PM q-Axis Inductance (mH/Phase) mH 2.06 2.21 1.46 1.28
E5-09 PM BackEMF Vpeak (mV/(rad/ s)) mVs/rad 524.1 583.7 563.6 601.2
E5-24 PM BackEMF L-L Vrms (mV/rpm) mV/(r/min) 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 87.5 87.5 87.5 87.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 87.5 87.5 87.5 87.5
E1-09 Min Output Frequency Hz 4.4 4.4 4.4 4.4
C5-17 Motor Inertia kgm
2
0.56 0.83 0.96 1.61
L3-24 Acc@Rated Torque
*1
s 0.208 0.254 0.243 0.338
n5-02 Mot Inertia Acceleration Time s 0.208 0.254 0.243 0.338
n8-49 Heavy Load Id Current % -17.0 -21.7 -10.9 -13.2
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
Table 11.7 SSR1 Series Motor Code Setting for Specification of 400 V at 1450 min
-1
(r/min)
Parameter Unit Motor Code (setting value of E5-01)
PM Mot Code Selection - 1332 1333 1335 1336 1338 133A 133B 133D
Voltage Class V 400 400 400 400 400 400 400 400
Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11
Motor Rotation Speed min
-1
1450 1450 1450 1450 1450 1450 1450 1450
PM Mot Rated Power (kW) kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11.0
PM Mot Rated Current (FLA) A 0.94 1.56 2.81 4.27 6.98 10.21 13.85 19.5
PM Mot Pole Count - 6 6 6 6 6 6 6 6
PM Mot Resistance (Ohms/Phase) Ω 12.760 7.421 4.825 2.656 1.353 0.999 0.713 0.393
PM d-Axis Inductance (mH/Phase) mH 128.60 85.11 58.87 46.42 31.73 26.20 27.06 15.51
