Omron Q2A Series Technical Manual

Parameter List
11
11.20 Parameters Changed by PM Motor Code Selection
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 499
Parameter Unit Motor Code (setting value of E5-01)
PM Mot Resistance (Ohms/Phase) Ω 0.028 0.024 0.015 0.011
PM d-Axis Inductance (mH/Phase) mH 2.32 2.20 1.45 1.23
PM q-Axis Inductance (mH/Phase) mH 2.97 3.23 1.88 1.67
PM BackEMF Vpeak (mV/(rad/ s)) mVs/rad 639.3 708.0 640.7 677.0
PM BackEMF L-L Vrms (mV/rpm) mV/(r/min) 0.0 0.0 0.0 0.0
Max Output Frequency Hz 72.5 72.5 72.5 72.5
Max Output Voltage V 380.0 380.0 380.0 380.0
Base Frequency Hz 72.5 72.5 72.5 72.5
Min Output Frequency Hz 3.6 3.6 3.6 3.6
Motor Inertia kgm
2
0.56 0.83 0.96 1.61
Acc@Rated Torque
*1
s 0.171 0.213 0.201 0.281
Mot Inertia Acceleration Time s 0.171 0.213 0.201 0.281
Heavy Load Id Current % -15.8 -19.6 -14.9 -15.1
*1 Default settings vary depending on the setting of Drive KVA Selection.
Table 11.10 SSR1 Series Motor Code Setting for Specification of 400 V at 1150 min
-1
(r/min)
Parameter Unit Motor Code (setting value of E5-01)
E5-01 PM Mot Code Selection - 1432 1433 1435 1436 1438 143A 143B 143D
Voltage Class V 400 400 400 400 400 400 400 400
Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11
Motor Rotation Speed min
-1
1150 1150 1150 1150 1150 1150 1150 1150
E5-02 PM Mot Rated Power (kW) kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11.0
E5-03 PM Mot Rated Current
(FLA)
A 0.94 1.51 3.00 4.43 7.08 10.10 13.33 19.9
E5-04 PM Mot Pole Count - 6 6 6 6 6 6 6 6
E5-05 PM Mot Resistance (Ohms/
Phase)
Ω 19.320 10.800 4.456 2.044 1.483 1.215 0.660 0.443
E5-06 PM d-Axis Inductance (mH/
Phase)
mH 194.70 129.20 76.88 48.60 37.58 44.54 26.36 19.10
E5-07 PM q-Axis Inductance (mH/
Phase)
mH 252.84 160.90 97.52 61.40 47.65 56.26 34.20 24.67
E5-09 PM BackEMF Vpeak (mV/
(rad/ s))
mVs/rad 640.9 654.1 728.8 688.9 702.0 861.5 783.0 762.2
E5-24 PM BackEMF L-L Vrms
(mV/rpm)
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-09 Min Output Frequency Hz 2.9 2.9 2.9 2.9 2.9 2.9 2.9 2.9
C5-17 Motor Inertia kgm
2
0.0017 0.0023 0.0083 0.0136 0.0171 0.027 0.046 0.055
L3-24 Acc@Rated Torque
*1
s 0.062 0.044 0.080 0.090 0.067 0.072 0.088 0.073
n5-02 Mot Inertia Acceleration
Time
s 0.062 0.044 0.080 0.090 0.067 0.072 0.088 0.073
n8-49 Heavy Load Id Current % -8.8 -9.9 -9.3 -10.0 -12.8 -12.3 -15.3 -16.7
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
Table 11.11 SSR1 Series Motor Code Setting for Specification of 400 V at 1150 min
-1
(r/min)
Parameter Unit Motor Code (setting value of E5-01)
E5-01 PM Mot Code Selection - 143E 143F 1440 1442 1443 1444
Voltage Class V 400 400 400 400 400 400
Capacity kW 15 18 22 30 37 45
