Parameter Details
12
12.7 H: TERMINALS
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 667
Note:
The default setting is 0 when the drive is initialized for 3-Wire Initialization [A1-03 = 3330].
■ H1-02 DI2 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H1-02
(0439)
DI2 Function Selection
Sets the function for MFDI terminal DI2.
2
(1 - 4, 6 - 19F)
Note:
The default setting is 0 when the drive is initialized for 3-Wire Initialization [A1-03 = 3330].
■ H1-03 DI3 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H1-03
(0400)
DI3 Function Selection
Sets the function for MFDI terminal DI3.
24
(0 - 19F)
■ H1-04 DI4 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H1-04
(0401)
DI4 Function Selection
Sets the function for MFDI terminal DI4.
7B
(0 - 19F)
■ H1-05 DI5 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H1-05
(0402)
DI5 Function Selection
Sets the function for MFDI terminal DI5.
A
(0 - 19F)
Note:
The default setting is 5 when the drive is initialized for 3-Wire Initialization [A1-03 = 3330].
■ H1-06 DI6 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H1-06
(0403)
DI6 Function Selection
Sets the function for MFDI terminal DI6.
B
(0 - 19F)
Note:
The default setting is A when the drive is initialized for 3-Wire Initialization [A1-03 = 3330].
■ H1-07 DI7 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H1-07
(0404)
DI7 Function Selection
Sets the function for MFDI terminal DI7.
6
(0 - 19F)
Note:
The default setting is B when the drive is initialized for 3-Wire Initialization [A1-03 = 3330].
■ H1-08 DI8 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H1-08
(0405)
DI8 Function Selection
Sets the function for MFDI terminal DI8.
Note:
The default setting is 6 when the drive is initialized for 3-Wire Initialization [A1-03 = 3330].
1B
(0 - 19F)
Note:
The default setting is 6 when the drive is initialized for 3-Wire Initialization [A1-03 = 3330].
