12.7 H: TERMINALS
668 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
■ H1-21 DI1 Funct.Sel 2
No.
(Hex.)
Name Description
Default
(Range)
H1-21
(0B70)
DI1 Funct.Sel 2
Sets the second function for MFDI terminal DI1.
0
(1 - 4, 6 - 19F)
When MFDI terminal DI1 activates, it will operate the function set to H1-01 [DI1 Function Selection] and the
function set to H1-21 at the same time.
When the setting value is 0, the function is disabled.
■ H1-22 DI2 Funct.Sel 2
No.
(Hex.)
Name Description
Default
(Range)
H1-22
(0B71)
DI2 Funct.Sel 2
Sets the second function for MFDI terminal DI2.
0
(1 - 4, 6 - 19F)
When MFDI terminal DI2 activates, it will operate the function set to H1-02 [DI2 Function Selection] and the
function set to H1-22 at the same time.
When the setting value is 0, the function is disabled.
■ H1-23 DI3 Funct.Sel 2
No.
(Hex.)
Name Description
Default
(Range)
H1-23
(0B72)
DI3 Funct.Sel 2
Sets the second function for MFDI terminal DI3.
0
(1 - 4, 6 - 19F)
When MFDI terminal DI3 activates, it will operate the function set to H1-03 [DI3 Function Selection] and the
function set to H1-23 at the same time.
When the setting value is 0, the function is disabled.
■ H1-24 DI4 Funct.Sel 2
No.
(Hex.)
Name Description
Default
(Range)
H1-24
(0B73)
DI4 Funct.Sel 2
Sets the second function for MFDI terminal DI4.
0
(1 - 4, 6 - 19F)
When MFDI terminal DI4 activates, it will operate the function set to H1-04 [DI4 Function Selection] and the
function set to H1-24 at the same time.
When the setting value is 0, the function is disabled.
■ H1-25 DI5 Funct.Sel 2
No.
(Hex.)
Name Description
Default
(Range)
H1-25
(0B74)
DI5 Funct.Sel 2
Sets the second function for MFDI terminal DI5.
0
(1 - 4, 6 - 19F)
When MFDI terminal DI5 activates, it will operate the function set to H1-05 [DI5 Function Selection] and the
function set to H1-25 at the same time.
When the setting value is 0, the function is disabled.
■ H1-26 DI6 Funct.Sel 2
No.
(Hex.)
Name Description
Default
(Range)
H1-26
(0B75)
DI6 Funct.Sel 2
Sets the second function for MFDI terminal DI6.
0
(1 - 4, 6 - 19F)
When MFDI terminal DI6 activates, it will operate the function set to H1-06 [DI6 Function Selection] and the
function set to H1-26 at the same time.
When the setting value is 0, the function is disabled.
