Parameter Details
12
12.10 o: KEYPAD
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 821
Stops the data log.
1 : ON (Data Logging)
Starts the data log as specified by the sampling cycle set in o5-02 [Log Sample Lapse].
■ o5-02 Log Sample Lapse
No.
(Hex.)
Name Description
Default
(Range)
o5-02
(1552)
RUN
Log Sample Lapse
Sets the data log sampling cycle. This parameter is only available on an LCD keypad.
1000 ms
(100 - 6000 ms)
■ o5-03 Log Mon Data 1
No.
(Hex.)
Name Description
Default
(Range)
o5-03
(1553)
RUN
Log Mon Data 1
Sets the data log monitor. This parameter is only available on an LCD keypad.
101
(000,101 - 855)
Note:
Set the log data with values 101 to 999 [U1-01 to U9-99].
For example, to show U1-05 [Motor Speed], set o5-03 = 105. When it is not necessary to set data log monitors, set this parameter to
000. You cannot set U2: FAULT or U3: FAULT HISTORY.
■ o5-04 Log Mon Data 2
No.
(Hex.)
Name Description
Default
(Range)
o5-04
(1554)
RUN
Log Mon Data 2
Sets the data log monitor. This parameter is only available on an LCD keypad.
102
(000,101 - 855)
Note:
Set the log data with values 101 to 999 [U1-01 to U9-99].
For example, to show U1-05 [Motor Speed], set o5-03 = 105. When it is not necessary to set data log monitors, set this parameter to
000. You cannot set U2: FAULT or U3: FAULT HISTORY.
■ o5-05 Log Mon Data 3
No.
(Hex.)
Name Description
Default
(Range)
o5-05
(1555)
RUN
Log Mon Data 3
Sets the data log monitor. This parameter is only available on an LCD keypad.
103
(000,101 - 855)
Note:
Set the log data with values 101 to 999 [U1-01 to U9-99].
For example, to show U1-05 [Motor Speed], set o5-03 = 105. When it is not necessary to set data log monitors, set this parameter to
000. You cannot set U2: FAULT or U3: FAULT HISTORY.
■ o5-06 Log Mon Data 4
No.
(Hex.)
Name Description
Default
(Range)
o5-06
(1556)
RUN
Log Mon Data 4
Sets the data log monitor. This parameter is only available on an LCD keypad.
107
(000,101 - 855)
Note:
Set the log data with values 101 to 999 [U1-01 to U9-99].
For example, to show U1-05 [Motor Speed], set o5-03 = 105. When it is not necessary to set data log monitors, set this parameter to
000. You cannot set U2: FAULT or U3: FAULT HISTORY.
