3-106
G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
3-7 Reactor Specifications
Connect to the servo drive for Reduction of Harmonic Emission. Select the model by the servo drive
model.
3-7-1 Specifications
Servo Drive Reactor
Model
Number of
power
phases
Model
Rated
current
Inductance Weight
R88D-KA5L- Single-phase 3G3AX-DL2002 1.6 A 21.4 mH Approx. 0.8 kg
R88D-K01L- 3G3AX-DL2004 3.2 A 10.7 mH Approx. 1.0 kg
R88D-K02L- 3G3AX-DL2007 6.1 A 6.75 mH Approx. 1.3 kg
R88D-K04L- 3G3AX-DL2015 9.3 A 3.51 mH Approx. 1.6 kg
R88D-K01H- Single-phase 3G3AX-DL2002 1.6 A 21.4 mH Approx. 0.8 kg
Three-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-K02H- Single-phase 3G3AX-DL2004 3.2 A 10.7 mH Approx. 1.0 kg
Three-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-K04H- Single-phase 3G3AX-DL2007 6.1 A 6.75 mH Approx. 1.3 kg
Three-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-K08H- Single-phase 3G3AX-DL2015 9.3 A 3.51 mH Approx. 1.6 kg
Three-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-K10H- Single-phase 3G3AX-DL2015 9.3 A 3.51 mH Approx. 1.6 kg
Three-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-K15H- Single-phase 3G3AX-DL2022 13.8 A 2.51 mH Approx. 2.1 kg
Three-phase 3G3AX-AL2025 10.0 A 2.8 mH Approx. 2.8 kg
R88D-K20H- Three-phase 3G3AX-AL2055 20.0 A 0.88 mH Approx. 4.0 kg
R88D-K30H-
R88D-K50H- 3G3AX-AL2110 37.0 A 0.35 mH Approx. 5.0 kg
R88D-K75H- 3G3AX-AL2220 70.0 A 0.18 mH Approx. 10.0 kg
R88D-K150H-
R88D-K06F- 3G3AX-AL4025 6.0 A 7.7 mH Approx. 2.7 kg
R88D-K10F-
R88D-K15F-
R88D-K20F- 3G3AX-AL4055 10.0 A 3.5 mH Approx. 4.0 kg
R88D-K30F-
R88D-K50F- 3G3AX-AL4110 20.0 A 1.3 mH Approx. 6.0 kg
R88D-K75F- 3G3AX-AL4220 36.0 A 0.74 mH Approx. 10.0 kg
R88D-K150F-

Omron R88M-K Specifications

General

Type	AC Servo Motor
Series	R88M-K
Protection Class	IP65
Rated Speed	3000 rpm
Ambient Temperature	0°C to 40°C
Vibration Resistance	4.9 m/s²
