Omron SYSDRIVE 3G3JV Series User Manual

8-3
Control
h
Overload capacity 150% of rated output current for 1 min
Control
charac-
teristics
External frequency set
signal
Selectable with FREQ adjuster: 0 to 10 VDC (20 kΩ), 4
to 20 mA (250 Ω), and 0 to 20 mA (250 Ω)
Acceleration/deceleration
time
0.0 to 999 s (Independent acceleration and deceleration
time settings: 2 types)
Braking torque Approx. 20%
Voltage/frequency
characteristics
Set a user V/f pattern
Protec-
ti
Motor protection Protection by electronic thermal
Protec
tive
func-
tions
Instantaneous
overcurrent protection
Stops at approx. 250% of rated output current
tions
Overload protection Stops in 1 min at approximately 150% of rated output
current
Overvoltage protection Stops when main-circuit DC voltage is approximately
410 V
Undervoltage protection Stops when main-circuit DC voltage is approximately
200 V (160 V for single-phase 200-VAC model)
Momentary power
interruption
compensation (selection)
Stops for 15 ms or more. By setting the Inverter to
momentary power interruption mode, operation can be
continued if power is restored within approximately 0.5 s.
Cooling fin overheating Detects at 110°C ± 10°C
Grounding protection Protection at rated output current level
Charge indicator (RUN
indicator)
Lit when the main circuit DC voltage is approximately
50 V or less.
Environ-
t
Location Indoors (with no corrosive gas, oil spray, or metallic dust)
Environ
ment
Ambient temperature Operating: –10°C to 50°C
Ambient humidity Operating: 90% max. (with no condensation)
Ambient temperature –20°C to 60°C
Altitude 1,000 m max.
Insulation resistance 5 MΩ min. (Do not carry out any insulation resistance or
withstand voltage tests)
Vibration resistance 9.8 m/s
2
{1G} max. between 10 to 20 Hz
2.0 m/s
2
{0.2G} max. between 20 and 50 Hz
Degree of protection Panel-mounting models: Conforms to IP20
Specifications Chapter 8

Omron SYSDRIVE 3G3JV Series Specifications

General

Model	SYSDRIVE 3G3JV Series
Category	Inverter
Output Frequency Range	0.1 to 400Hz
Frequency Range	50/60Hz
Control Method	PWM Control
Overload Capacity	150% for 1 minute
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooling
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20°C to +65°C
Humidity	90% RH or less (non-condensing)
Altitude	1000m or less
Vibration	5.9 m/s² or less
Braking Unit	Built-in
Communication	RS-485
Voltage Class	200V class, 400V class
Input Voltage	3-phase 200 to 240V AC, 3-phase 380 to 480V AC
