Omron SYSDRIVE 3G3JV Series User Manual

4-5
7. No-load Operation
Start the no-load motor using the Digital Operator.
 Set the frequency reference using the Digital Operator and start the motor using
key sequences.
8. Actual Load Operation
Connect the mechanical system and operate using the Digital Operator.
 When
there are no dif ficulties using the no-load operation, connect the mechanical
system to the motor and operate using the Digital Operator.
9. Operation
Basic Operation:
Operation
based on the basic settings required to start and stop the Inverter . Refer to
page 5-1.
Advanced Operation:
Operation that uses PID control or other functions. Refer to page 6-1.
 For operation within standard parameters, refer to Chapter 5 Basic Operation .
 Refer
to Chapter 5 Basic Operation and Chapter 6 Advanced Operation for the vari -
ous
advanced functions, such as stall prevention, carrier frequency setting, over -
torque detection, torque compensation, and slip compensation.
Test Run Chapter 4

Omron SYSDRIVE 3G3JV Series Specifications

General

Model	SYSDRIVE 3G3JV Series
Category	Inverter
Output Frequency Range	0.1 to 400Hz
Frequency Range	50/60Hz
Control Method	PWM Control
Overload Capacity	150% for 1 minute
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooling
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20°C to +65°C
Humidity	90% RH or less (non-condensing)
Altitude	1000m or less
Vibration	5.9 m/s² or less
Braking Unit	Built-in
Communication	RS-485
Voltage Class	200V class, 400V class
Input Voltage	3-phase 200 to 240V AC, 3-phase 380 to 480V AC
