3-47
3-7 Parameter List
3
Operation
Others
C101 UP/DWN selection
00: Do not store the frequency data
01: Store the frequency data
00 No Yes  4-88
C102 Reset selection
00: Trip reset at power-on
01: Trip reset when the power is OFF
02: Enabled only during trip (Reset when the
power is ON)
03: Trip reset only
00 Yes Yes 
4-85
4-132
C103
Reset frequency
matching selection
00: 0 Hz start
01: Frequency matching start
02: Frequency pull-in restart
00 No Yes  4-85
Meter adjustment
C105 MP gain setting 50. to 200. 100. Yes Yes % 4-107
C106 AM gain setting 50. to 200. 100. Yes Yes %
4-108
C107 AMI gain setting 50. to 200. 100. Yes Yes %
C109 AM bias setting 0. to 100. 0. Yes Yes %
C110 AMI bias setting 0. to 100. 20. Yes Yes %
Terminal
C111
Overload warning
level 2
0.0 to 2.00 × Rated current (0.4 to 55 kW)
0.0 to 1.80 × Rated current (75 to 132 kW)
Rat-
ed
cur-
rent
Yes Yes A 4-49
Adjustment
C121 FV zero adjustment
0. to 9999.
1000 to 6553 (10000 to 65530)
Factor
y
defaul
t
Yes Yes 
C122 FI zero adjustment
0. to 9999.
1000 to 6553 (10000 to 65530)
Factor
y
defaul
t
Yes Yes 
C123 FE zero adjustment
0. to 9999.
1000 to 6553 (10000 to 65530)
Factor
y
defaul
t
Yes Yes 
Parameter
No.
Function name Monitor or data range
Default
setting
Changes during
operation
Unit Page
Normal
b031 = 10
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
