Configuration
C200H PC
A
B
A
B
A
B
A
B
A
B
20
13
12
11
10
Emergency
stop
CW limit
CCW limit
Origin
Origin
proximity
Position Control Unit
24 VDC
Feeding is executed to positions lying at equal distances in the same direc-
tion from a specific point, repeatedly using the same positioning action and
then RESET ORIGIN.
ORIGIN
SEARCH
Origin
0
Origin proximity
signal
RESET ORIGIN
Operation
Positioning at Intervals Using RESET ORIGIN Section 5–2
