84
Time
Origin proximity
signal
Z-phase signal
Pulse output
Origin adjustment
command
Pulse output
Origin adjustment
command
1
0
1
0
1
0
1
0
Stop
Stop
Time
(Long deceleration time)
(Short deceleration time)
4–3–4 Completion Examples
Completion Patterns With an Origin Proximity Signal
The following two example diagrams both illustrate completion of ORIGIN
SEARCH when an origin proximity signal is present (i.e., when DIP switch
no. 3 is ON). There is an origin compensation value set in the second exam-
ple, but not in the first.
ORIGIN SEARCH Section 4–3
To Next Page
