90
0
1
0
1
0
1
0
1
0
1
0
1
0
1
Input
6000
Time
Emergency stop signal
START
IR n, bit 00
RELEASE PROHIBIT
IR n, bit 04
Pulse output
Emergency Stop flag
IR n+5, bit 04
Error flag
IR n+5, bit 05
No-origin flag
IR n+5, bit 11
Busy flag
IR n+5, bit 12
Alarm/error code
IR n+6
ORIGIN SEARCH
IR n, bit 02
0000
0
1
Origin search begun
Turns OFF when origin search is completed
The emergency stop flag is not affected by exceeding the CW or CCW limit.
When a limit is exceeded, only pulse output in the opposite direction is possi-
ble. In other words, when the CW limit is exceeded, only CCW pulse output is
possible. Although a CCW HIGH-SPEED JOG is used to clear the CW limit
flag in the example, LOW-SPEED JOG or ORIGIN SEARCH may also be
used.
Example 2: Exceeding CW
or CCW Limit
RELEASE PROHIBIT Section 4–5
