50
Group DescriptionName
DM
(data memory)
Go To Page Displays the contents of the data memory in the system work area in pages
(units of 160 words). The data can be altered with this function. (C-series PCs
only)
Copy Copies the contents of the DM area of the system work area (data memory
information).
Fill Writes the same data to more than one data word in the system work area data
memory area.
Print Prints a specified range of DM words.
Hex <—> ASCII Specifies the display mode for the data memory contents when the work disk
data memory contents are to be altered. The display mode can be hexadecimal
or ASCII.
Save DM Data Writes the contents of a specified range of system work area data memory to
the data disk.
Retrieve DM Data Retrieves the saved data disk data memory to the system work area DM area.
Read DM
Address
Used to display DM data from the work disk up to 160 words at a time.
Displayed data can be modified. (CVM1 PCs only)
Switch Bank
Number
Used to specify the Expansion DM bank on the work disk. (CVM1 PCs only)
Save file
Used to save file data (with an .IOM) extension from the work disk to a data
disk. (CVM1 PCs only)
Retrieve file
Use to retrieve file data (with an .IOM extension) from a data disk to the work
disk. (CVM1 PCs only)
I/O Table Write I/O Table Edits the I/O table in the system work area.
Check I/O Table Checks the contents of the I/O table in the system work area.
Save I/O Table Writes the I/O table in the system work area to a data disk.
Retrieve I/O Table Retrieves the I/O table data stored on a data disk to the system work area.
Clear I/O Table
Used to delete the I/O table from the work disk. (CVM1 PCs only)
Custom I/O
Table SIOU
Used to specify CPU Bus Unit classifications. (CVM1 PCs only)
Print I/O Table Prints an I/O table list. (C-series PCs only)
Support Software Capabilities Section 4-1
