Omron VARISPEED L7 User Manual

5-23
5
V/f Pattern 2: E3
E2-11
Motor rated
output
power
Sets the rated output power of the
motor.
This parameter is an input data for
autotuning.
0.00 to
650.00
3.70
*2
No Q Q Q - 318H 6-59
Mtr Rated
Power
E2-12
Motor iron
saturation
coefficient 3
This parameter is automatically set
during rotating autotuning.
1.30 to
1.60
1.30 No - A A - 328H 6-59
Saturation
Comp3
*1. The setting range is 10% to 200% of the Inverter's rated output current. The given value is for a 400 V inverter with 3.7 kW.
*2. The factory setting depends upon the Inverter capacity. The given value is for a 400 V inverter with 3.7 kW.
*3. The setting range depends on the inverter capacity and on the setting of E2-01. The maximum value is E2-01 minus 0.01A. The given setting range is
for a 400 V inverter with 3.7 kW.
Param
eter
Num-
ber
Name
Description
Set-
ting
Range
Fac-
tory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Regis-
ter
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
Display
E3-01
Control mode
selection
Sets the contol mode for motor 2.
0:V/f control
2:Open Loop Vector control
3:Closed Loop Vector control for
induction motors
0 to 3 0 No A A A - 319H 6-59
Control Method
E3-02
Max. output fre-
quency
(FMAX)
To set V/f characteristics in a straight
line, set the same values for E1-07
and E1-09. In this case, the setting
for E1-08 will be disregarded.
Always ensure that the four frequen-
cies are set in the following manner:
E1-04 (FMAX) ≥ E1-06 (FA) > E1-
07 (FB) ≥ E1-09 (FMIN)
40.0 to
120.0
50.00
Hz
No A A A - 31AH 6-59
Max Frequency
E3-03
Max. output
voltage
(VMAX)
0.0 to
510.0
*1
*1. These are values for a 400 V Class Inverter.
400.0
V
*1
No A A A - 31BH 6-59
Max Voltage
E3-04
Base frequency
(FA)
0.0 to
120.00
50.00
Hz
No A A A - 31CH 6-59
Base Frequency
E3-05
Mid. output fre-
quency (FB)
0.0 to
120.0
i
No
A
(2.5)
A
(3.0)
--31DH6-59
Mid Frequency
E3-06
Mid. output fre-
quency voltage
(VB)
0.0 to
510
*1
i
No
A
30.0
V
*1
A
26.4
V
*1
--31EH6-59
Mid Voltage
E3-07
Min. output fre-
quency (FMIN)
0.0 to
120.0
i
No
A
1.2
Hz
A
0.5 Hz
A
0.0 Hz
-31FH6-59
Min Frequency
E3-08
Min. output fre-
quency voltage
(VMIN)
0.0 to
510.0
*1
i
No
A
18.0
V
*1
A
4.8 V
*1
- - 320H 6-59
Min Voltage
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Regis-
ter
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
Display
Output Voltage (V)
Frequency (Hz)
