Omron VARISPEED L7 User Manual

5-24
5
Motor 2 Setup: E4
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
Display
E4-01
Motor rated
current
Sets the motor rated current.
This set value will become the refer-
ence value for motor protection and
torque limits.
This parameter is an input data for
autotuning.
0.85 to
17.00
*1
*1. The setting range is 10% to 200% of the Inverter's rated output current. The given value is for a 400 V inverter with 3.7 kW.
7.00 A
*2
*2. The factory setting depends upon the Inverter capacity. The given value is for a 400 V inverter with 3.7 kW.
No A A A - 321H 6-59
Motor Rated
FLA
E4-02
Motor rated
slip
Sets the motor rated slip.
This set value will become the refer-
ence value for the slip compensation.
This parameter is automatically set
during autotuning.
0.00 to
20.00
2.70 Hz
*2
No A A A - 322H 6-59
Motor Rated
Slip
E4-03
Motor no-
load current
Sets the motor no-load current.
This parameter is automatically set
during autotuning.
0.00 to
13.99
*3
*3. The setting range depends on the inverter capacity and on the setting of E2-01. The maximum value is E2-01 minus 0.01A. The given setting range is for a
400 V inverter with 3.7 kW.
2.30 A
*2
No A A A - 323H 6-59
No-Load
Current
E4-04
Number of
motor poles
Sets the number of motor poles.
This value is an input data for autotun-
ing.
2 to 48 4 poles No - - A - 324H 6-59
Number of
Poles
E4-05
Motor line-
to-line resis-
tance
Sets the motor phase-to-phase resis-
tance.
This parameter is automatically set
during autotuning.
0.000
to
65.000
3.333 Ω
*2
No A A A - 325H 6-59
Term Resis-
tance
E4-06
Motor leak
inductance
Sets the voltage drop due to motor
leakage inductance as a percentage of
the motor rated voltage.
This parameter is automatically set
during autotuning.
0.0 to
40.0
19.3%
*2
No - A A - 326H 6-59
Leak Induc-
tance
E4-07
Motor rated
power
Sets the motor rated power.
0.00 to
650.00
3.70
kW
No A A A - 327H 6-59
Mtr Rated
Power
