Omron VARISPEED L7 User Manual

5-25
5
PM Motor Setup: E5
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
Display
E5-02
Motor rated
power
Sets the motor rated power.
0.00 to
300.00
3.7kW
*1
*1. The factory setting depends upon the Inverter capacity. The given value is for a 400V class inverter with 3.7 kW.
No - - - Q 32AH 6-62
Rated power
E5-03
Motor rated
current
Sets the motor rated current.
This set value will become the refer-
ence value for motor protection and
torque limits.
0.00 to
200.00
*2
*2. The setting range is 10% to 200% of the Inverter's rated output current. The given value is for a 400 V class inverter of 3.7 kW is given.
7.31A
*1
No - - - Q 32BH 6-62
Rated cur-
rent
E5-04
Number of
motor poles
Sets the number of motor poles. 2 to 48 4 poles No - - - Q 32CH 6-62
Number of
Poles
E5-05
Motor line-
to-line resis-
tance
Sets the motor phase-to-phase resis-
tance.
0.000
to
65.000
1.326 Ω
*1
No - - - Q 32DH 6-62
Term Resis-
tance
E5-06
D-Axis
Inductance
Sets the motors d-axis inductance
0.00 to
300.00
19.11
mH
*1
No - - - Q 32EH 6-62
Leak Induc-
tance
E5-07
Q-Axis
Inductance
Sets the motors q-axis inductance
0.00 to
600.00
26.08
mH
*1
No - - - Q 32FH 6-62
Leak Induc-
tance
E5-09
Motor volt-
age constant
Sets the motor voltage constant.
50.0 to
4000.0
478.6
mV
*1
No - - - Q 330H 6-62
Voltage con-
stant
