Omron VARISPEED L7 User Manual

5-35
5
Analog Inputs: H3
Con-
stant
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO
BUS
Regis-
ter
Page
Display V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
H3-01
*1
AI-14B Channel 1
signal level selection
Selects the input signal level of
Channel 1 if an AI-14B option
card is installed.
0:0 to +10V
1:-10 to +10V
0 or 1 0 No A A A A 410H 6-25
AI-14 CH1 LvlSel
H3-02
*1
AI-14B Channel 1
gain
Sets the frequency reference
value when 10 V is input as a per-
centage of the maximum output
frequency set in E1-04.
0.0 to
1000.0
100.0% Yes A A A A 411H 6-25
AI-14 CH1 Gain
H3-03
*1
AI-14B Channel 1
bias
Sets the frequency reference
value when 0 V is input as a per-
centage of the maximum output
frequency set in E1-04.
-100.0
to
+100.0
0.0% Yes A A A A 412H 6-25
AI-14 CH1 Bias
H3-04
*1
AI-14B Channel 3
signal level selection
Selects the input signal level of
Channel 3 if an AI-14B option
card is installed.
0:0 to 10V
1:-10 to +10V
0 or 1 0 No A A A A 413H 6-25
AI-14 CH3 LvlSel
H3-05
*1
AI-14B Channel 3
function selection
Selects the function for the chan-
nel 3 input if an AI-14B option
card is installed. See the table
below for the available functions.
2,3,14 2 No A A A A 414H 6-25
AI-14 CH3FuncSel
H3-06
*1
AI-14B Channel3
gain
Sets the input level according to
the 100% value of the function
set in parameter H3-05 when the
voltage at channel 3 of the
AI-14B option card is 10 V.
0.0 to
1000.0
100.0% Yes A A A A 415H 6-25
AI-14 CH3 Gain
H3-07
*1
AI-14B Channel 3
Bias
Sets the input level according to
the 0% value of the function set
in parameter H3-05 when the
voltage at channel 3 of the
AI-14B option card is 0 V.
-100.0
to
+100.0
0.0% Yes A A A A 416H 6-25
AI-14 CH3 Bias
H3-08
*1
AI-14B Channel 2
signal level selection
Selects the input signal level of
Channel 2 if an AI-14B option
card is installed.
0:0 to 10V
1:-10 to +10V
2:4 to 20 mA.
If current input is selected, chan-
nel 2 must be set to current input
by hardware as well. Refer to the
AI-14B manual.
0 to 2 0 No A A A A 417H 6-25
AI-14 CH2 LvlSel
H3-09
*1
AI-14B Channel 2
function selection
Selects the function for the chan-
nel 2 input if an AI-14B option
card is installed. See the table
below for the available functions.
2, 3, 14 3 No A A A A 418H 6-25
AI-14 CH2FuncSel
H3-10
*1
AI-14B Channel 2
Gain
Sets the input level according to
the 100% value of the function
set in parameter H3-09 when the
voltage/current at channel 2 of
the AI-14B option card is 10V/
20mA.
0.0 to
1000.0
100.0% Yes A A A A 419H 6-25
AI-14 CH2 Gain
H3-11
*1
AI-14B Channel 2
Bias
Sets the input level according to
the 0% value of the function set
in parameter H3-09 when the
voltage/current at channel 2 of
the AI-14B option card is 0V/
0mA.
-100.0
to
+100.0
0.0% Yes A A A A 41AH 6-25
AI-14 CH2 Bias
