5-34
5
12 Timer function output Yes Yes Yes Yes 6-52
13
f
ref
/f
set
agree 2 (detection width L4-04 is used)
Ye s Yes Ye s Ye s 6-26
14
f
ref
/f
set
agree 2 (ON: Output frequency = L4-03, with detection width L4-04 is used, and dur-
ing frequency agree)
Ye s Yes Ye s Ye s 6-26
15 Frequency detection 3 (ON: Output frequency ≤ -L4-03, detection width L4-04 is used) Yes Yes Yes Yes 6-26
16 Frequency detection 4 (ON: Output frequency ≥ -L4-03, detection width L4-04 is used) Yes Yes Yes Yes 6-26
17 Car stuck/undertorque detection 1 NC (NC Contact, OFF: Torque detection) Yes Yes Yes Yes 6-40
18 Car stuck/undertorque detection 2 NO (NO Contact, ON: Torque detection) Yes Yes Yes Yes 6-40
19 Car stuck/undertorque detection 2 NC (NC Contact, OFF: Torque detection) Yes Yes Yes Yes 6-40
1A During reverse run (ON: During reverse run) Yes Yes Yes Yes 6-57
1B During baseblock 2 (OFF: During baseblock) Yes Yes Yes Yes 6-57
1C Motor 2 selected (ON: Motor 2 (E3- and E4-) is selected) Yes Yes Yes No 6-62
1D During regenerative operation No No Yes Yes 6-58
1E Restart enabled (ON: Automatic fault restart enabled) Yes Yes Yes Yes 6-81
1F Motor overload (OL1, including OH3) pre-alarm (ON: 90% or more of the detection level) Yes Yes Yes Yes 6-44
20 Inverter overheat (OH) pre-alarm (ON: Temperature exceeds L8-02 setting) Yes Yes Yes Yes 6-47
30 During torque limit (current limit) (ON: During torque limit) No Yes Yes Yes 6-43
33 Zero-servo end (ON: Zero-Servo completed) No No Yes Yes 6-16
37
During run 2 (ON: Frequency output, OFF: Base block, DC injection braking, initial excita-
tion, operation stop)
Ye s Yes Ye s Ye s 6-56
38 Cooling fan running Yes Yes Yes Yes 6-58
40 Brake Release Command Yes Yes Yes Yes
6-13
6-58
41 Output Contactor Close Command Yes Yes Yes Yes
6-13
6-58
42 Speed detection at deceleration (Door zone) Yes Yes Yes Yes 6-58
43 Not Zero Speed Yes Yes Yes Yes 6-58
44 Light load direction output (ON: Forward, OFF: Reverse) Yes Yes Yes Yes 6-80
45 Light load detection status (ON: Ready for light load test, OFF: Light load test in progress) Yes Yes Yes Yes 6-80
46 Hardware base block monitor 1 (ON: terminal BB and BB1 closed) Yes Yes Yes Yes 6-58
47 Hardware base block monitor 2 (ON: terminal BB or BB1 off) Yes Yes Yes Yes 6-58
Setting
Value
Function
Control Methods
Page
V/f
Open
loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
