Omron VARISPEED L7

5-40
5
Torque Detection: L6
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
Display
L6-01
Torque
detection selec-
tion 1
0:Torque detection disabled.
1:Car stuck detection only with
speed agreement; operation
continues (warning is output).
2:Car stuck detected continu-
ously during operation; opera-
tion continues
(warning is output).
3:Car stuck detection only with
speed agreement; output
stopped upon detection.
4:Car stuck detected continu-
ously during operation; output
stopped upon detection.
5:Undertorque detection only
with speed agreement; opera-
tion continues (warning is out-
put).
6:Undertorque detected continu-
ously during operation; opera-
tion continues
(warning is output).
7:Undertorque detection only
with speed agreement; output
stopped upon detection.
8:Undertorque detected continu-
ously during operation; output
stopped upon detection.
0 to 8 4 No A A A A 4A1H 6-40
Torq Det 1 Sel
L6-02
Torque detection
level 1
Vector control: Motor rated torque
is set as 100%.
V/f control: Inverter rated current
is set as 100%.
0 to 300 150% No A A A A 4A2H 6-40
Torq Det 1 Lvl
L6-03
Torque detection
time 1
Sets the overtorque/undertorque
detection time.
0.0 to
10.0
10.0 s No A A A A 4A3H 6-40
Torq Det 1 Time
L6-04
Torque detection
selection 2
See L6-01 to L6-03 for a descrip-
tion.
0 to 8 0 No A A A A 4A4H 6-40
Torq Det 2 Sel
L6-05
Torque detection
level 2 0 to
300
150% No A A A A 4A5H 6-40
Torq Det 2 Lvl
L6-06
Torque detection
time 2
0.0 to
10.0
10.0 s No A A A A 4A6H 6-40
Torq Det 2 Time
