Omron VARISPEED L7 User Manual

5-51
5
Special Sequence Functions: S3
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
Display
S3-01
Short-floor
function selec-
tion
Enables or disables the short floor
operation function
0:disabled
1:enabled (Standard)
2:enabled (Advanced)
0 or 1 0 No A A A A 6BDH 6-17
Short floor sel
S3-03
Inspection
deceleration
time
Sets the deceleration time for the
inspection run.
0.0 to
2.0
0.0sec No A A A A 6BFH 6-11
Dec ramp inspec
S3-04
Nominal/Level-
ing speed detec-
tion level
Sets the speed level for Nominal/
Leveling speed detection when
multispeed inputs are used.
(d1-18=0/3)
0.0 to
120.0
0.0Hz No A A A A 6C0H 6-6
Vn/Vl level sel
S3-05
Nominal speed
for short floor
calculation
Sets the nominal speed value
which is used for the short floor
calculation.
0.0 to
120.0
0.0Hz No A A A A 6C1H 6-16
Vn@ Short floor
S3-06
Light load
search for res-
cue operation
Enables or disables the Light load
search function for rescue opera-
tion.
0:disabled
1:enabled
2:enabled (for motor 1 only)
0 or 2 0 No A A A A 6C2H 6-80
LightLoad
Search
S3-07
Light load
search time
Sets the light load search time for
the rescue operation.
0.0 to
5.0
1.0 sec No A A A A 6C3H 6-80
LightLd Srch-
Time
S3-08
Output phase
order
Sets the output phase order.
0:Output phase order is U-V-W
1:Output phase order is U-W-V
0 or 1 0 No A A A A 6C4H 6-63
Exchg Phase Sel
S3-09
Frequency refer-
ence loss detec-
tion
Enables or disables the frequency
reference loss detection when d1-
18 = 1 and H1-K83.
0:Disabled
1:Enabled
0 or 1 1 No A A A A 6C5H 6-8
FRL selection
S3-10
Light load
search fre-
quency
Sets the light load speed for the
rescue operation.
0.00 to
20.00
3.00 Hz No A A A A 6C6H
6-77
LightLd Srch-
Freq
S3-11
Rescue opera-
tion torque limit
Sets the torque limit for the rescue
operation.
0 to 300 100 % No - A A A 6C7H 6-77
Rescue OP
TLM
S3-12
Base Block
restart selection
Sets the behaviour of the inverter
if a Base Block command is set
during run.
0:Disabled
The Run command must be
cycled to restart.
1:Enable
The inverter restarts when the
Base Block signal is released
and the Run signal is still active.
0 or 1 0 No A A A A 6C8H 6-50
BB Restart
S3-13
Traction sheave
diameter
Sets the diameter of the traction
sheave.
100 to
2000
400
mm
No A A A A 6C9H 6-65
Sheave diameter
