Omron VARISPEED L7 User Manual

5-58
5
U1-44
ASR output
without filter
Monitors the output from the
speed control loop (i.e., the pri-
mary filter input value). 100%
is displayed for rated second-
ary current of the motor.
10 V: Rated secondary cur-
rent of motor
(-10 V to 10 V)
0.01% - - A A 6BH
ASR Out w/o Fil
U1-45
Feed forward
control output
Monitors the output from feed
forward control. 100% is dis-
played for rated secondary cur-
rent of the motor.
10 V: Rated secondary cur-
rent of motor
(-10 V to 10 V)
0.01% - - A A 6CH
FF Cout Output
U1-50
Slip compensa-
tion value
Monitors the slip compensation
value.100% is displayed
for rated slip
10 V: Rated slip of motor
(-10 V to 10 V)
0.01% A A - - 71H
Slip comp value
U1-51
Max Current
during accelera-
tion
Monitors the maximum current
during acceleration.
10 V: Rated current of motor
(0 V to 10 V)
0.1 A A A A A 72H
MaxCur-
rent@Acc
U1-52
Max Current
during decelera-
tion
Monitors the maximum current
during deceleration.
10 V: Rated current of motor
(0 V to 10 V)
0.1 A A A A A 73H
MaxCur-
rent@Dec
U1-53
Max Current
during Top
speed
Monitors the maximum current
at top speed.
10 V: Rated current of motor
(0 V to 10 V)
0.1 A A A A A 74H
MaxCur-
retn@Run
U1-54
Max Current
during leveling
speed
Monitors the maximum current
at Vl speed.
10 V: Rated current of motor
(0 V to 10 V)
0.1 A A A A A 75H
Max Amp
at Vl sped
U1-55
Number of trav-
els
Monitors the lift operation
counter.
Using parameter O2-15 the
counter can be cleared.
(Cannot be output.) - A A A A 76H
No of travels
U1-56
*1
AI-14B channel
1 input level
Monitors the input level of ana-
log input 1 on a AI-14B option
board. A value of 100% is equal
to 10V input.
10 V: 100%
(-10 to 10 V)
0.1% A A A A 77H
AI-14 Ch1
InpLvl
U1-57
Car acceleration
rate
Shows the elevator car acceler-
ation rate value.
10V: 9.8 m/s²
(-10V to 10 V)
0.01
m/s²
AA A A 57H
Cage accel
U1-74
q-axis motor
current refer-
ence
Monitors the q-axis current ref-
erence.
10 V: Motor rated current
(-10 to 10 V)
0.1% A A A A 7C6H
Iq Reference
U1-75
d-axis motor
current refer-
ence
Monitors the d-axis current ref-
erence.
10 V: Motor rated current
(-10 to 10 V)
0.1% A A A A 7C7H
Id Reference
*1. The parameter is displayed only if a AI-14B option board is installed.
Param-
eter
Num-
ber
Name
Description
Output Signal Level During
Multi-Function Analog Output
Min.
Unit
Control Methods
MEMO-
BUS
Register
V/f
Open
Loop
Vector
Closed
Loop
Vector
Closed
Loop
Vector
(PM)
Display
