10-10
10
o1-01 Monitor selection 6
o1-02 Monitor selection after power up 1
o1-03 Frequency units of reference setting and monitor 0
o1-04 Setting unit for frequency parameters related to V/f characteristics 0
o1-05 LCD Display contrast adjustment 3
o2-01 LOCAL / REMOTE key enable/disable 0
o2-02 STOP key during control circuit terminal operation 0
o2-03 User parameter initial value 0
o2-04 kVA selection 0
o2-05 Frequency reference setting method selection 0
o2-06 Operation selection when digital operator / LED monitor is disconnected 0
o2-07 Cumulative operation time setting 0 hr.
o2-08 Cumulative operation time selection 0
o2-09 Initialize Mode 2
o2-10 Fan operation time setting 0 hr.
o2-12 Fault trace initialize 0
o2-15 “No of Travels” monitor initialize 0
o3-01 Copy function selection 0
o3-02 Read permission selection 0
S1-01 Zero speed level at stop 0.5 Hz
S1-02 DC injection braking current at start 50%
S1-03 DC injection braking current at stop 50%
S1-04 DC injection braking time at start 0.40 sec
S1-05 DC injection braking time at stop 0.60
S1-06 Brake release delay time 0.20
S1-07 Brake close delay time 0.10
S1-14 SE2 detection delay time 200 msec
S1-15 SE3 detection delay time 200 msec
S1-16 Run delay time 0.10 sec.
S1-17 DC injection current gain at regenerative operation 100%
S1-18 DC injection current gain at motoring operation 20%
S1-19 Output contactor open delay time 0.10 sec.
S1-20 Zero servo gain 5
S1-21 Zero servo completion width 10
S1-22 Starting torque compensation increase time 500 msec
S1-23 Torque compensation gain during lowering 1.000
S1-24 Torque compensation bias during raising 0.0%
S1-25 Torque compensation bias during lowering 0.0%
S1-26 Dwell speed at start reference 0.0 Hz
S1-27 Door zone speed level 0.0 Hz
S1-28 SE1 detection selection 0
S1-29 Torque compensation fade out level 0.0 Hz
S1-30 Torque compensation fade out time 1000 msec
S1-31 Torque limit time at stop 0 msec
S2-01 Motor rated speed 1380 rpm
S2-02 Slip compensation gain in motoring mode 0.7
S2-03 Slip compensation gain in regenerative mode 1.0
S2-05 Slip compensation torque detection delay time 1.0 sec.
No. Name
Factory
Setting
Setting
