Section 2 UPGRADING THE SYSTEM
ZN
System Manual
Section 2
Setup Methods Suited to Specific Applications
2. Connecting peripheral devices
Connect the Air Clean Unit, Air Particle Sensor, Interface Unit, and the personal computer, and turn the
power supply of all of these devices ON.
Before connecting these devices, turn their power supplies OFF.
System Configuration Examples p.7, p.9
3. Checking system operation
Make sure that the Air Particle Sensor and Interface Unit have started up normally.
• When the Air Particle Sensor has not started up normally:
Check the Sensor connection. Also, refer to the Instruction Sheet for the Air Particle Sensor in the
case of other errors.
• When the Interface Unit has not started up normally:
Make sure that the Air Particle Sensor Amplifier Unit is in the RUN mode. Also, check the
connections of the peripheral devices.
2sysup.fm26ページ２００７年６月２８日 木曜日 午前９時１７分
To Next Page
