23
En
You can switch inputs to select the desired source
component. Choose an input from the following:
LINE1, LINE2, LINE3, LINE4, LINE5, PHONO
(D1, D2, D3 (A-9050 only))
The LED corresponding to the selected input will light up.
Tip
• The LED will blink when D1, D2 or D3 is selected and a signal
is not input. (A-9050 only)
■ Operating with the remote controller
■ Operating on the integrated amplifier
By bypassing the tone control circuit, the Direct function
uses the shortest path for enhanced sound quality. Also,
since the left/right balance setting uses a system that
doesn’t affect the sound quality, the balance can be
adjusted even if the Direct function is enabled.
From the warm low notes produced by a cello to the deep
frequencies of electronic music, a good compact audio
system should be able to deliver plenty of bass resonance.
While traditional enhancement systems effectively boost
low-frequency sound, they are often prone to the effects of
phase shifting, which can overwhelm mid-range
frequencies and muddy the sound.
Our Phase-Matching Bass Boost technology effectively
preserves mid-range clarity-allowing vocals and strings to
shine-while maintaining a smooth, powerful bass response
at all volume levels.
• When the DIRECT function is on, turn the function off
to use the PHASE MATCHING BASS effect.
Selecting the Input Source
1
Press INPUT!/" repeatedly.
1
Use the INPUT selector.
INPUT !/"
INPUT selector
Using the Direct Function
1
Press the DIRECT button.
The DIRECT LED lights.
Using the PHASE MATCHING BASS
Function
1
Press the PHASE MATCHING BASS button.
The PHASE MATCHING BASS LED lights up.
DIRECT LED DIRECT button
PHASE MATCHING
BASS LED
PHASE MATCHING
BASS button
To Next Page
