Onkyo A-9030 Owner's Manual

28
En
Specifications
■ Audio Inputs
■ Audio Outputs
■ Others
Specifications and features are subject to change without notice.
A-9050 A-9030
Rated Output Power (North American)
(FTC) 75 watts minimum continuous power per
channel, 8 ohm loads, 2 channels driven at 1 kHz,
with a maximum total harmonic distortion of 0.08 %
(FTC) 65 watts minimum continuous power per
channel, 4 ohm loads, 2 channels driven at 1 kHz,
with a maximum total harmonic distortion of 0.08 %
(European)
(IEC) 2 ch × 75 W at 8 ohms, 1 kHz, 2 ch Driven of
0.08 %
(IEC) 2 ch × 65 W at 8 ohms, 1 kHz, 2 ch Driven of
0.08 %
Maximum Effective
Output Power
(Asian)
(JEITA) 2 ch × 80 W at 4 ohms, 1 kHz, 2 ch driven
THD+N (Total Harmonic Distortion+N)
0.08 % (Rated Output Power) 0.08 % (Rated Output Power)
Damping Factor 60 (Front, 1 kHz, 8 Ω) 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance (Unbalance)
175 mV/33 kΩ (LINE)
4.8 mV/47 kΩ (PHONO MM)
175 mV/33 kΩ (LINE)
4.8 mV/47 kΩ (PHONO MM)
Rated RCA Output Level and Impedance
0.175 V/2.2 kΩ (REC OUT) 0.175 V/2.2 kΩ (REC OUT)
Phono Overload 100 mV (MM 1 kHz 0.5 %) 100 mV (MM 1kHz 0.5%)
Frequency Response 10 Hz - 100 kHz/+1 dB, –3 dB (LINE1) 10 Hz - 100 kHz/+1 dB, –3 dB (LINE1)
Tone Control Characteristies
+14 dB, –14 dB, 100 Hz (BASS)
+14 dB, –14 dB, 10 kHz (TREBLE)
+0 dB, –14 dB (BALANCE)
+8 dB, 80 Hz (PM.BASS)
+14 dB, –14 dB, 100 Hz (BASS)
+14 dB, –14 dB, 10 kHz (TREBLE)
+0 dB, –14 dB (BALANCE)
+8 dB, 80 Hz (PM.BASS)
Signal to Noise Ratio 110 dB (LINE, IHF-A)
80 dB (PHONO MM, IHF-A)
105 dB (LINE, IHF-A)
80 dB (PHONO MM, IHF-A)
Speaker Impedance 4 Ω – 16 Ω 4 Ω – 16 Ω
Power Supply (North American) AC 120 V, 60 Hz
(European) AC 230 V, 50 Hz
(European) AC 230 V, 50 Hz
(Asian) AC 220 V, 50 Hz
Power Consumption 160 W (European) 135 W
(Asian) 125 W
No-sound Power Consumption
(North American) 45 W
(European) 50 W
35 W
Stand-by Power Consumption
(North American) 0.2 W
(European) 0.3 W
0.3 W
Dimensions (W × H × D)
435 mm × 139 mm × 330.3 mm
17-1/8" × 5-1/2" × 13"
435 mm × 139 mm × 330.3 mm
17-1/8" × 5-1/2" × 13"
Weight 8.2 kg (18.1 lbs) 7.4 kg (16.3 lbs)
Digital Inputs 1 (Rear Optical)
2 (Rear Coaxial)
Analog Stereo Inputs LINE1, LINE2, LINE3, LINE4, LINE5, PHONO LINE1, LINE2, LINE3, LINE4, LINE5, PHONO
Analog Stereo Outputs LINE OUT, PRE OUT LINE OUT
Subwoofer Pre Outputs 11
Speaker Outputs SP-A, B SP-A, B
Phones 1 (6.3 ø) 1 (6.3 ø)
u
11

Onkyo A-9030 Specifications

General

Damping factor	60
Amplifier class	A/B
Frequency range	10 - 100000 Hz
Output impedance	8 Ω
Audio output channels	2.0 channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	105 dB
Total Harmonic Distortion (THD)	0.08 %
RMS power output per channel (1 Ohm)	65 W
Audio (L/R) in	5
Audio (L/R) out	1
Speakers connectivity type	Clamp terminals
Purpose	Home
Material	Aluminium, Metal
Product color	Silver
Volume control	Rotary
Bass adjustment	Yes
Connectivity technology	Wired
Built-in display	No
AC input voltage	220-230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	135 W
Package weight	9400 g

Weight and Dimensions

Depth	330.3 mm
Width	435 mm
Height	139 mm
Weight	7400 g
