Opengear ACM7000 User Manual

Chapter 7: Power, Environmental & Digital I/O
156
9. Check Log Status and specify the Log Rate if you wish to log the status from this RPC. These logs
can be views from the Status > RPC Status screen
10. Click Apply
11. For SNMP PDUs the console server probes the configured RPC to confirm the RPC Type matches
and will report the number of outlets it finds that can be controlled. If unsuccessful it will report
Unable to probe outlets and you’ll need to check the RPC settings or network/serial connection
12. For serially connected RPC devices, a new managed device with the same name as given to the
RPC will be created. The console server will configure the RPC with the number of outlets
specified in the selected RPC Type or will query the RPC for this information
NOTE Opengear’s console servers support the majority of the popular network and serial PDUs. If your
PDU is not on the default list, support can be added directly or by having the PDU added to either
the Network UPS Tools or PowerMan open source projects.
IPMI service processors and BMCs can be configured so all authorized users can use the
Management Console to remotely cycle power and reboot computers, even when their operating
system is unresponsive. To set up IPMI power control, an administrator enters the IP
address/domain name of the BMC or service processor (e.g. a Dell DRAC) in Serial & Network >
Network Hosts, in Serial & Network > RPC Connections specifies the RPC Type to be IPMI1.5 or
2.0

Opengear ACM7000 Specifications

General

RS-232 ports	8
SIM card slot	Yes
USB 2.0 ports quantity	4
Number of simultaneous SIM cards	2
Certification	EN 55022:2010, CISPR 22:2008, FCC Part 15 B:2015, ICES-003 5 (2014), AS/NZS CISPR 22:2009+A1:2010, EN 61000-3-2:2006/A2:2009, EN 61000-3-3:2008 EN 55024:2010, CISPR 24:2010, EN 61000-4-2:2009, EN 61000-4-3:2006+A2:2010, EN 61000-4-4:2004+A1:2010, EN 61000-4-5:2006, EN 61000-4-6:2009, EN 61000-4-8:2010, EN 61000-4-11:2004 CE, UL 1950, TUV, C-Tick, RoHS
Mounting type	Rack mounting
Product color	Black, Red
Antenna connector type	SMA
Flash memory	32 MB
Internal memory	256 MB
Processor frequency	800 MHz
Control display unit	No
Internal memory type	DDR3
Input voltage	110 - 240 V
DC input voltage	12 V
Storage temperature (T-T)	-40 - 75 °C
Operating temperature (T-T)	-25 - 60 °C
Operating relative humidity (H-H)	5 - 90 %
Security algorithms	IPSec, SSH-2, SSL/TLS

Weight and Dimensions

Depth	120 mm
Width	130 mm
Height	35 mm
Weight	6000 g
