Tactile position 1
Zone B is located between the first tactile position and the second tactile
position.
Tactile position 2
Zone C is located between the second tactile position and the stop limit.
2 Lateral buttons
3 Connection cable
To connect the pedal to the socket on the rear panel of the R-EVO SMART.
4 Nameplate data label
Contains data such as manufacturer, serial number of the instrument, year of
manufacture of the Medical Device, etc.
5 Adjustable feet
These feet can be folded down, allowing you to adjust the height of the back
of the pedal to two positions.
The multi-function pedal can be programmed via the R-EVO SMART monitor-touch
screen. For more details, see chapter "5.6.8 Programming the pedal"
