TECHNICAL SPECIFICATIONS
3.6 GENERAL SPECIFICATIONS
PARAMETERS SPECIFICATION
Manufacturer: ...................... OPTIKON 2000 S.p.A.
via del Casale di Settebagni, 13
00138 Rome - Italy
Model:................................ R-Evo Smart E/R-Evo Smart S/R-Evo Smart CR
Compliance with regulations: ... 93/42/EEC Medical Device Directive (MDD)
Technical standards: ............. EN60601-1; EN60601-1-2; EN60601-2-2 EN80601-2-58
ENVIRONMENTAL SPECIFICATIONS
Storage and transport: ............ temperature from -10°C to +70°C,
humidity 10-100% (non-condensing),
atmospheric pressure 500 - 1060 hPa
Operation: ........................... temperature range from + 10 ° C to + 35 ° C,
humidity 30-75%,
atmospheric pressure 900 - 1060 hPa (for maximum
vacuum); 810 - 1060 hPa (for vacuum up to 500mmHg)
ELECTRICAL SPECIFICATIONS
Input Voltage: ...................... 100-240 Vac.
Frequency: .......................... 50/60 Hz
Required power: ................... 200 VA
Fuses: ................................ 100-240 Volt: T3.15AH 250V
COMPRESSED AIR SPECIFICATIONS (Reco Smart S and CR models only)
Inlet air pressure: .................. from 500 and 800 kPa (from 72 and 116 PSI)
Air consumption: ................... 32 Normal litres/minute
IRRIGATION
Fluid delivery: ...................... by gravity; eye pressure determined by the height of the
irrigation source, or Controlled
Valves: ............................... solenoid driven pinch valve
Control: .............................. System pedal
ASPIRATION
Aspiration pump types: ........... R-Evo Smart E: Peristaltic
R-Evo Smart S and CR: Peristaltic and Venturi
Actuating medium: ................ (Venturi pump) pressurized air coming from an external
source at 500 ÷ 800 KPa (72 ÷ 116 PSI)
Default vacuum level: ............. user programmable
Available vacuum range:.......... from 5 to 650 mmHg
Default flow rate: .................. user programmable
