Technical specification
Version 1.0.2 dated 2018-03-02 Page 19Translation of the original instructions
DH45V GB
DH45V_GB_2.fm
OPTIMUM
MASCHINEN - GERMANY
®
2.1 Emissions
CAUTION!
The user must wear noise protection and hearing protection.
The A-weighted sound pressure level L
pA
is 84 to 87 dB.
The A-weighted sound power level L
WA
is 99 to 103 dB.
INFORMATION
This numerical value was measured on a new machine under the operating conditions specified
by the manufacturer. The noise behaviour of the machine might change depending on the age
and wear of the machine.
Furthermore, the noise emission also depends on production engineering factors, e.g. speed,
material and clamping conditions.
INFORMATION
The following factors influence the actual degree of the noise exposure of the operator:
Characteristics of the working area, e.g. size or damping behaviour,
other noise sources, e.g. the number of machines,
other processes taking place in proximity and the period of time, during which the operator
is exposed to the noise.
Furthermore, it is possible that the admissible exposure level might be different from country to
country due to national regulations.
Maximum distance [mm]
spindle - stand
1210
Working surface stand [mm]
Length x Width of the working surface
755 x 480
Dimensions of the machine
"Dimensions“ on page 21
Required space
Keep a work area of at least one metre around the machine free for
operation and maintenance.
Machine weight [kg] 550
Gross weight (Packing + accessory) [ kg ] 660
Packing dimension L x B x H 2440 x 770 x 1110
Spindle speeds [ rpm
]
Number of stages
Column diameter [mm] Ø 150 mm
Environmental conditions temperature 5 - 35 °C
Environmental conditions
Relative humidity
25-80%
Gear operating material 3 litres Mobilgear 629
"Lubricant“ on page 63
Operating material
Toothed rod and drill column
acid-free oil
Coolant system max. 5 liters
"Lubricant“ on page 63
DH45V
