2 Technical specification
The following information represents the dimensions and indications of weight and the manu-
facturer‘s approved machine data.
Electrical connection
Motor 400V ~ 50Hz / 3Ph. 1,1/ 1,5 kW
optional 400V / 3Ph. ~ 60Hz 1,1/ 1,5 kW
440V / 3 Ph. ~ 60Hz 1,1/ 1,5 kW
230V / 1Ph. ~ 50Hz 1,1 kW
230V / 3Ph. ~ 60Hz 1,1/ 1,5 kW
Drilling-milling capacity
Drilling capacity in steel [mm] max. Ø 28
Drilling capacity in cast [mm] max.
Ø 32
Milling capacity end mill [mm] max.
Ø 28
Milling capacity milling head [mm] max.
Ø 63
Throat [mm] 275
Spindle seat
Spindle seat MT 4
Draw-in rod M16
Spindle sleeve stroke [mm] 120 mm
Drill-mill head
Swivelling + / - 60°
Gear stages 2 x 6
Z axis travel [mm] 430
Milling table
Table length [mm] 800
Table width [mm] 240
Y axis travel [mm] 195
X axis travel [mm] 450
T - slot size / distance [mm] 14 / 63
Max. load [kg] 80
Dimensions
Height [mm]  Installation plan on page 20
Length [mm]
Width [mm]
Total weight [kg] 320
