4.2 Safety
The drilling- milling machine must only be operated under the following conditions:
The drilling- milling machine is in proper working order.
The drilling- milling machine is used as intended.
The operating manual is followed.
All safety devices are installed and activated.
Eliminate or have all malfunctions rectified promptly. Stop the drilling- milling machine immedi-
ately in the event of any abnormality in operation and make sure it cannot be started up acci-
dentally or without authorisation.
For your own safety during operation on page 15
4.3 Switching on the drilling-milling machine
ATTENTION!
Wait until the drilling-milling machine has come to a complete halt before changing the
rotation direction using the rotation direction switch.
Select the rotation direction of the drilling-milling machine using the rotation direction
switch.
Two speed stages are available for each rotation direction.
The marking "R" means clockwise rotation.
The marking "L" means anticlockwise rotation.
Press the button "ON".
The drilling-milling machine switches on and turns in the preselected rotation direction.
Changing the speed range on page 28
4.4 Switching off the drilling-milling machine
Press the button "OFF" or switch the rotation direction switch to the neutral position.
4.5 Inserting the tool
4.5.1 Installation
CAUTION!
When milling, the seat cone must always be secured with the draw-in rod. A simple
connection with the taper bore of the work spindle without using the draw-in rod is not
permissible for milling. The cone connection is released by lateral pressure. Injuries may
be caused by parts flying off.
