Optos 200tx - Using False Color views; Viewing stereo images

Chapter 7 - Using the viewing options
1. Select the image you want to display using the Simulated BIO view.
2. Select Image menu > Simulated BIO View to simulate the BIO view. "Simulated BIO View" will appear in the
image window title.
3. Repeat the previous step to return the image to the standard view.
Note
In previous versions of the software this view was called "Targeted Ophthalmoscopy View".
Using False Color views
The False Color
1
views are only available when the Green Channel view or Red Channel view have been selected.
The False Color views can make some subtle features more obvious.
1. Select the image you want to display using the False Color views.
2. Select either the Green Channel view or Red Channel view.
3. Select Image menu > False Color > ...and select either:
l
Off - switches off False Color if in use.
l
Fire - shows the current image in tones ranging from dark red, red, orange, yellow to white.
l
Spectrum - shows the current image in tones ranging from purple, blue, green yellow to white.
4. Optional: Right click to change the size of the magnified area.
Note
On systems where the Magnifier is available, you can display the full image in the Composite Color view and
use the False Color views on the Magnifier area, see Using the Magnifier on page 45.
Viewing stereo images
Stereo Images are a pair of images of the same eye. Each image is taken with the patient aligned slightly off
center; with one image captured when the patient is aligned slightly to the left and the other when aligned
slightly to the right.
The viewing technique being used should be selected before the images are opened, see Setting User
Preferences on page 15. This ensures the images are displayed on the correct side of the screen for the
technique being used.
Caution
Stereo Images should not be used for diagnostic purposes.
1. Open the Stereo Images, see How to open stereo images on page 37.
2. If using a Stereo Overlay, you should manually register the images to ensure the optic disk and
macula positions match, see Registering Image Reference Points.
3. Using your preferred reviewing technique, review the images using a stereo viewer (stereograph)
or focus either beyond or in front of the two images, until you see the images as one.
Note
l
You will need to close and reopen the Stereo Images if you change the user setting options during
the review.
l
The Adjustment and Information panels are automatically hidden when Stereo Images are
displayed. You can display them if required, see Using the Adjustment and Information panels
on the facing page.
1
Replaces grey scale with a range of colors. This may help accentuate the differences in the image
intensity.
48 of 100
