Chapter 9 - Distributing images
1. Select Review Menu > Patient History to display the Select Patient dialog box and select the patient record you
want to import the image into.
2. Select Tools menu > Import Image > Left Eye (Right Eye or Set) to display the Select Image to Import dialog box.
Selecting Set lets you import images from an optomap® fa sequence.
3. Select the file (or files) you want to import and click Open.
4. Confirm that the image is to be assigned to the current patient.
Note
l
You can also drag and drop images from Windows Explorer directly into the Patient History view. Drop
the image on to the correct side of the window, either Right or Left Eye Thumbnail Images pane.
l
optomap® fa cannot be imported as a series from Windows Explorer. To maintain image series links,
you must import the images using the Set option.
Printing images
The Review application includes a variety of printing functions. The functions let you select and adjust
images and define the layout of the page.
Caution
The use of a print as an assist to diagnosis is determined by the clinician.
You can print the current image by clicking the print button. This will send a Quick Print directly to the default
printer.
You can print single or multiple images by placing each image or image sequence on the Print Bar. The Print
Bar is located at the bottom of the Review application window.
You can print the current image for the patient to takeaway. You can customize the layout, for example to
display your logo.
How to print the current image as displayed
1. Open and zoom into the area you want to print.
2. Select the annotations you want to print, see How to show/hide annotations on page 53.
3. Select File menu > Print Active Image to display the image in the Print Images dialog box.
4. The Print Images tabs contain a variety of settings:
l
Image Layout tab - lets you select the layout style. You can select the additional information you
want to include.
l
Image Adjustment tab - lets you adjust the Contrast, Brightness and Gamma settings for the
selected image. The histogram shows the distribution of the pixels in the image as the
settings are adjusted.
l
Click Optimize to automatically set the print settings to produce a clear, bright image.
l
Click Restore to restore the default settings.
l
Click Equalization to brighten the superior field to match the brightness of the central pole.
Note
The quality of the prints can vary between printers. You can usually achieve the best print quality by
using good quality ink, for example using the printer manufacturer's own ink. The type of paper used
has a significant effect on the way the ink is applied. Using paper that does not match the paper type
selected can often result in a very poor quality print. You should always use the paper that matches the
selected paper type, for example, photo or glossy paper.
How to print a set of images
You can print, adjust and change the layout of the images that have been dragged on to the Print Bar.
