Management Ethernet Link Alarms
The following table lists the NIU management Ethernet port alarms:
Table 6-7 Management Ethernet Link Alarms
Alarm Name Alarm
Severity
Cause(s) Example Log
Message
Graphic Display
Message
LINK UP ALARM
VXINTF
MINOR Mgmt0 link up Port 0 UP X LINK ALARMS
(where X is number of
alarming links)
LINK UP ALARM
VXINTF
MINOR Mgmt1 link up Port 1 UP X LINK ALARMS
LINK UP ALARM
VXINTF
MINOR Mgmt2 link up Port 2 UP X LINK ALARMS
LINK DOWN
ALARM VXINTF
MAJOR Mgmt0 link down Port 0 DOWN X LINK ALARMS
LINK DOWN
ALARM VXINTF
MAJOR Mgmt1 link down Port 1 DOWN X LINK ALARMS
LINK DOWN
ALARM VXINTF
MAJOR Mgmt2 link down Port 2 DOWN X LINK ALARMS
SFP+ Presence Alarms
The following table lists the alarms that reflect when an SFP+ module is inserted or
removed from an NIU:
Table 6-8 SFP+ Presence Alarms
Alarm Name Alarm Severity Cause(s) Example Log
Message
Graphic Display
Message
SFP+ REMOVED
GIGPORT 0
CRITICAL S0P0 SFP+
Removed
Slot 0 Port 0 SFP+
Removed
N/A
SFP+ INSERTED
GIGPORT 0
CRITICAL S0P0 SFP+
Inserted
Slot 0 Port 0 SFP+
Inserted
N/A
SFP+ REMOVED
GIGPORT 1
CRITICAL S1P0 SFP+
Removed
Slot 1 Port 0 SFP+
Removed
N/A
SFP+ INSERTED
GIGPORT 1
CRITICAL S1P0 SFP+
Inserted
Slot 1 Port 0 SFP+
Inserted
N/A
SFP+ REMOVED
GIGPORT 2
CRITICAL S0P1 SFP+
Removed
Slot 0 Port 1 SFP+
Removed
N/A
SFP+ INSERTED
GIGPORT 2
CRITICAL S0P1 SFP+
Inserted
Slot 0 Port 1 SFP+
Inserted
N/A
SFP+ REMOVED
GIGPORT 3
CRITICAL S1P1 SFP+
Removed
Slot 1 Port 1 SFP+
Removed
N/A
SFP+ INSERTED
GIGPORT 3
CRITICAL S1P1 SFP+
Inserted
Slot 1 Port 1 SFP+
Inserted
N/A
SFP+ REMOVED
GIGPORT 4
CRITICAL S2P0 SFP+
Removed
Slot 2 Port 0 SFP+
Removed
N/A
SFP+ INSERTED
GIGPORT 4
CRITICAL S2P0 SFP+
Removed
Slot 2 Port 0 SFP+
Removed
N/A
