DC Power Supply Physical Dimensions
Table 7-3 Acme Packet 6300/6350 DC Power Supply Physical Dimensions
(continued)
Specification Description
Height 1.575” (4.0 cm)
Width 2.146” (5.45 cm)
Depth 13.26” (33.68 cm)
Weight 2lbs., 0 oz. (1.05 kg)
Important: This equipment is intended for installation in Network Telecommunication
Facilities.
Fan Module Specifications
Table 7-4 Acme Packet 6300/6350 Fan Module Specifications
Specification Description
Number of Fans 15
Total Maximum Airflow 300 CFM
Electrical Specifications
Refer to the following tables for information regarding the electrical specifications of
the Acme Packet 6300/6350.
Power Supply Input Circuit Fuse Requirements
Table 7-5 Acme Packet 6300/6350 Power Supply Input Circuit Fuse
Requirements
Power Circuit Fuse Rating Power cable size
120 VAC 15 AMP 18 AWG
240 VAC 7.5 AMP 18 AWG
-48 VDC 35 AMP min 10 AWG
Alarm Port Dry Contact Current Limits
Table 7-6 Acme Packet 6300/6350 Alarm Port Dry Contact Current Limits
Specification Value
Max AC switching current 0.3 A @ 125 VAC
Max DC switching current 1 A @ 30 VDC
Chapter 7
Electrical Specifications
7-2
