Location of the SSM3 Module (Mounted on Acme Packet 6300/6350)
Pre-Installation Guidelines
Please read and follow these pre-installation guidelines prior to replacing the SSM3
module:
• The SSM3 module can be installed only in the designated location.
• Note the installation location of the SSM3 module on the NIU PCB.
• Ground yourself and follow proper ESD grounding procedures.
• Remove the SSM3 from the shipped packaging.
• Install the SSM3 according to the procedure below.
• This upgrade should be performed during low-traffic periods or during times of
scheduled maintenance.
• Follow industry-standard procedures to ensure ESD protection.
• When installing or removing an NIU card, move the card to an ESD-safe location.
Note:
Before handling a Acme Packet 6300/6350 NIU card, follow the proper
ESD grounding procedures. Failure to do so could damage the NIU card
and its components.
Chapter 6
Replacing the SSM3 Module
6-18
