Remove PCIe Card From PCIe Riser
148 Oracle Database Appliance Service Manual • June 2017
■
“Install PCIe Card in PCIe Riser” on page 150
■
“Remove Primary HBA PCIe Card From Motherboard” on page 153
■
“Install Primary HBA PCIe Card in Motherboard” on page 154
PCIe Card Configuration
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
The Oracle Database Appliance Version 1 PCIe expansion system includes one standalone
low-profile slot on the motherboard and a PCIe riser with three slots. These are provisioned as
follows:
■
Motherboard slot – A low-profile, dual-port SAS-2 HBA used internally
■
PCIe slot 2 – Dual-port SAS-2 HBA used internally
■
PCIe slot 1 – Quad-port 1-Gb Ethernet NIC
■
PCIe slot 0 – Dual-port 10-Gb Ethernet NIC
Caution - If you replace a PCIe card, ensure the replacement is identical to the card you are
replacing.
Remove PCIe Card From PCIe Riser
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes removing a PCIe card from its riser in Oracle Database Appliance
Version 1.
1.
Prepare the server node for service.
a.
Attach an antistatic wrist strap.
See “Performing Electrostatic Discharge and Antistatic Prevention
Measures” on page 112.
