Persistent Reserve In
Julyl 2017 Command Set 173
Type When the Reservation Holder Bit is 1, this field indicates the type of
Persistent Reservation:
3h = Exclusive Access
6h = Exclusive Access - Registrants Only
8h = Exclusive Access - All Registrants
Relative Target Port
Identifier
1 = Target Port 1
2 = Target Port 2
Transport ID Data This field identifies the initiator port that is part of the I_T nexus or I_T
nexuses described by this full status descriptor.
• TABLE 4-93 shows the Transport ID returned for a Fibre Channel
Host.
• TABLE 4-94 shows the transport ID data returned for a SAS Host.
Read Full Status Descriptor Data Definitions:
TABLE 4-93 Fibre Channel Transport ID Data
Byte
Bit
76543210
0 Format Code (00b) Reserved Protocol Identifier (0h)
1 to 7 Reserved
8 to 15 N_Port_Name
16 to 23 Reserved
Fibre Channel Transport ID Data Definitions:
Protocol Identifier This field is set to 0h indicating the Fibre Channel protocol
N_PORT_NAME This field specifies the N_Port_Name that is returned by the initiator in the
PLOGI extended link service frame.
