Oracle storagetek sl150

Tape Slot Locations
Julyl 2017 Locations 245
FIGURE A-3 Non-Partitioned 10 Module Library with 3 Reserved Cells and the Standard Mailslot
Configuration
1. Module 1 (Base)
2. Robot
3. Power supplies
4. Standard mailslots
5. Left magazine front
6. Right magazine front
7. Storage slots
8. Reserved slots (configurable)
9. Tape drives
10. Module 10 (Expansion)
