Tape Slot Locations
Julyl 2017 Locations 243
Library Configuration and Slot Maps
FIGURE A-1 shows a library with a base module, no reserved cells and the standard
mailslot configuration.
FIGURE A-2 shows a library with 2 modules, no reserved cells, and the expanded
mailslot configuration.
FIGURE A-3 shows a library with 10 modules, 3 reserved cells, and the standard
mailslot configuration.
FIGURE A-4 shows a library with 15 modules, 3 reserved cells, and the standard
mailslot configuration.
FIGURE A-1 Non-Partitioned 1 Module Library with No Reserved Cells and the Standard Mailslot
Configuration
1. Module 1 (Base)
2. Robot
3. Power supplies
4. Standard mailslots
5. Left magazine front
6. Right magazine front
7. Storage slots
8. Tape drives
