Partitioning—General
Julyl 2017 Partitioning Overview 251
FIGURE B-1 Example of a 10 Modular Tape Library with 2 Partitions, 3 Reserved Cells, and the
Standard Mailslot Configuration
1. Module 1 (Base)
2. Partition 1
3. Partition 2
4. Robot
5. Power supplies
6. Tape drives
7. Standard Mailslots
8. Left magazine front
