Mode Select (6)

58 SL150 Interface Reference Manual Julyl 2017

Mode Select (6) Data

The initiator must provide mode parameter data in a parameter list including:

• “Mode Select (6) Parameter Header” on page 58

• “Fibre Channel Disconnect/Reconnect Page (HP Bridged)” on page 59

• “SAS Disconnect/Reconnect Page (HP Bridged)” on page 61

• “Fibre Channel Logical Unit Page (HP Bridged)” on page 63

• “SAS Logical Unit Page (HP Bridged)” on page 64

• “Fibre Channel Port Control Page (HP Bridged)” on page 65

• “SAS Port Control Page (HP Bridged)” on page 68

• “SAS Phy Control and Discover Mode Subpage (HP Bridged)” on page 70

• “Informational Exceptions TapeAlert Page” on page 73 or

• “Element Address Assignment Mode Page” on page 75

Note – Before issuing any Mode Select commands, an initiator should issue a Mode

Sense command with the Page Control field set to 01h, and the Page Code field set to

3Fh to determine which pages are supported, which parameters within the pages are

changeable, and the supported length of each page.

Mode Select (6) Parameter Header

The library returns a four-byte Mode Select parameter header as follows:

Note – The header definitions for the library must all be 00h.

TABLE 4-25 Mode Select Parameter (6) Header

Byte

Bit

76543210

0 Reserved (00h)

1 Reserved (00h)

2 Reserved (00h)

3 Reserved (00h)
