Mode Select (10)
Julyl 2017 Command Set 87
Fibre Channel Port Control Page (HP Bridged)
TABLE 4-42 shows the format of the Fibre Channel Port Control page.
TABLE 4-42 Fibre Channel Port Control Page
Byte
Bit
76543210
0 PS (0) SPF (0) Page Code (19h)
1 Page Length (06h)
2 Reserved Protocol Identifier (0)
3 DTFD PLPB DDIS DLM RHA ALWI DTIPE DTOLI
4 Reserved
5 Reserved
6 Reserved RR_TOV units
7 Resource Recovery Time Out Value (RR_TOV)
Fibre Channel Port Control Page Definitions:
PS The Parameters Saveable bit is set to 0.
SPF The library returns a value of:
0 = SubPage Format bit, indicating page_0 format is being used
Protocol Identifier This field is set to:
0h indicating the Fibre Channel protocol
DTFD Disabled Target Fabric Discovery. If the library is not attached to an arbitrated
loop, it shall ignore the DTFD bit.
0 = The target attached by an arbitrated loop shall discover a fabric loop
port if present on the loop and perform the public loop functions defined
for targets by FC-FLA.
1 = The target attached by an arbitrated loop shall not recognize the
presence of a fabric loop port on the loop.
PLPB Prevent Loop Port Bypass. If the library is not attached to an arbitrated loop, it
shall ignore the PLPB bit.
0 = The target allows the Loop Port Bypass (LPB) and Loop Port Enable
(PBE) primitive sequences to control the port bypass circuit and
participation on the loop as specified by FC-AL-2.
1 = The target attached to an FC-AL-2 loop shall ignore any Loop Port
Bypass (LPB) and Loop Port Enable (LPE) primitive sequences.
