Mode Select (6)
76 SL150 Interface Reference Manual Julyl 2017
Mode Select (6) Element Address Assignment Mode Page Definitions:
PS The Parameters Saveable bit is set to 0.
Page Code Identifies the Element Address Assignment mode page.
Parameter Length Indicates the length of the element address assignment parameter list.
This field must be 12h, which indicates that there are an additional 12h
(18d) bytes of parameter data following this byte.
First Medium Transport
Element Address
Identifies the address of the hand in the library.
This field must be set to 0000h (0d).
Number of Medium
Transport Elements
Identifies the number of hands in the library.
The library has only one hand, so this field must be 0001h (1d).
First Storage Element
Address
Identifies the starting address of the cartridge tape storage cells in the library.
This field must be set to 03E8h (1000d).
Number of Storage
Elements
Identifies the number of cartridge tape storage cells in the library.
This number is based on the configuration of the library and is obtained
when the library performs a Mode Sense of mode page 1Dh.
The number in the Mode Select command must be the same number
returned by the Mode Sense command.
First Import/Export
Element Address
Identifies the address of the first Import/Export element.
This field must be set to 000Ah (10d).
Number of Import/Export
Elements
Identifies the number of Import/Export storage locations. This value is
obtained when the library performs a Mode Sense of mode page 1Dh.
The number in the Mode Select command must be the same number
returned by the Mode Sense command.
First Data Transfer
Element Address
Identifies the first tape drive or drive slot. If the Address All Drive Slots
option is set, then the first Data Transfer Element Address may be an empty
drive slot.
This field must be set to 01F4h (500h).
Number of Data Transfer
Elements
Identifies the number of tape drives. If the Address All Drive Slots option is
set, then the number of Data Transfer Elements includes all empty and full
drive slots.
This number varies depending on the configuration. Obtain this value by
requesting a Mode Sense of mode page 1Dh.
The number in the Mode Select command must be the same number
returned by the Mode Sense command.
