Orange Pi R1 Plus - Ethernet Port Test; Wan Port Test

range Pi 用户手册 深圳市迅龙软件有限公司版权所有
www.orangepi.cn
31
www.xunlong.tv
of the TF card
9) After the system starts, execute the df -h command to check the size of rootfs. If it is
consistent with the actual capacity of the TF card, it can also indicate that the expansion
is successful
rroot@OpenWrt:/# df -h
Filesystem Size Used Available Use% Mounted on
/dev/root 14.5G 238.7M 14.3G 2% /
tmpfs 495.6M 2.8M 492.8M 1% /tmp
tmpfs 512.0K 0 512.0K 0% /dev
cgroup 495.6M 0 495.6M 0% /sys/fs/cgroup
3.4.
Ethernet port test
3.4.1.
Wan port test
1) First, insert the network cable into the usb to Ethernet interface of the development
board, and ensure that the network is unblocked
