48
The control panel uses the ETSI ES 201 912 protocol 1 to send SMS message via a standard
phone line. This protocol is not supported worldwide so please check with your telephone
provider. If the SMS message feature is required, the SMS-Service Centre number must be
configured. Listed below are the SMS Centre numbers for supported countries and operators:
SMS-Service details are subject to change. It is advised to check with the relevant
operator to obtain up to date SMS-Service settings.
Caller Line Identity must be enabled for the SMS Service Centre to accept the message.
Ethernet settings
When an Ethernet Module is fitted the following options must be configured:
0 Address
A valid IP address must be assigned to the module. It must be entered in dot-decimal notation,
e.g. “192.168.0.58”.
1 Mask
The subnet mask used on the network must be assigned to the module. It must be entered in
dot-decimal notation, e.g. “255.255.255.0”.
2 Gateway
The gateway address (normally the ADSL router) used on the network must be assigned to the
module. It must be entered in dot-decimal notation, e.g. “192.168.0.1”.
3 Port
A valid port number must be assigned to the module. It must be entered as a decimal number,
e.g. “10001”.
Wi-Fi settings
When a Wi-Fi Module is fitted the following options must be configured:
0 SSID
