3. Hold the B / o or @ key for 2 seconds to exit the menu.
Coms Modules
The control panel supports various communication modules (except CK-10 and CT-10). This
menu allows you to configure the settings for each module.
GSM Settings
When a GSM Module is fitted the following options must be configured:
0 APN Name
The Access Point Name (APN) is used by the GSM network operator for IP packet data
communication – this is required for the GSM to communicate IP information (APP/ ARC/ UDL
usage). The table below shows the APN settings used by the major UK GSM network operators:
* = leave blank
1 APN User
The APN user name used
to log into the APN–
please refer to table 1 for
additional information.
2 APN Password
The APN password used
to log into the APN–
please refer to table 1 for
additional information.
3 SIM Pin
The SIM passcode (if the
sim is locked).
4 SIM Credit
Code
By entering this code (obtained by the service provider) the system can give an up to date
credit balance on (PAYG) Pay As You Go sim cards.
APN details are subject to change. It is advised to check with the network provider to
obtain up to date APN settings.
SMS-Service Settings
When a PSTN Module is fitted to the system, it is possible to send SMS messages to mobile
telephones via a standard phone line (PSTN). For example, an end user can receive a text
message with full description (e.g., ‘Zone 02 – Kitchen PIR – Area 1 at 10:45 01/01/16’).
