Method for mechanical back angle adjustment
12
Folding up the back support
1) Fold the back support up.
2) Push the lock lever down (see fig.12, item1).
3) Place the cross bolt on the end of the gas compres
sion spring into the bracket (see fig.12, item2).
4) Release the lock lever until the cross bolt engages.
5) Check to ensure the lock is securely engaged by
pulling on the back support.
Folding down the back support
1) Push the lock lever down (see fig.12, item1).
2) Remove the cross bolt at the end of the gas com
pression spring from the bracket (see fig.12,
item2).
3) Fold the back support down onto the seat.
8.4.2 Adjusting the back support angle
The angle of the backrest can be adapted to the requirements of the user.
Adjusting the back angle using the strap
The adjustment is carried out as described in the previous section.
Manual back angle adjustment
If needed, the back angle is adjusted, as needed by using this seat function (see Page37).
8.5 Getting in and transferring
CAUTION
Incorrect handling when getting in
Falling, tipping over due to incorrect handling
► Turn the control unit off while getting in and out, in order to avoid accidental driving.
► Always place the seat in a horizontal position.
► Note that the armrests are not capable of bearing full body weight, and therefore must not be used for getting
into or out of the wheelchair.
► Always put on a lap belt when driving.
CAUTION
Incorrect handling when getting in
Crushing, pinching, impacts due to incorrect handling
► Do not reach into the danger area with your fingers when folding the legrest or footplates up or down.
► Never step on the footplates when getting in and out.
► Note projecting edges.
The modular design of the power wheelchair and the ease with which you can remove the side panels and legrests
make it easy to get into and out of the wheelchair from the side or from the front.
Users can choose the method for getting into and out of the wheelchair which is most suitable for them.
22
Use
A200
